B6X Belt Conveyor

Belt conveyor is a kind of machine that transfers the material continuously. Vipeak belt conveyor is advanced and simple in structure easy to maintain. Transfer capacity is more higher and transfer distance more longer. It is widely used in mining metallurgical and coal industry .

Raw Materials:

Cement, silicate product, new building materials, refractory material, chemical fertilizer, nonferrous and ferrous metal beneficiation and glass ceramic industries.

Application:

Limestone, calcite, coal ash, kaolin, calcium carbonate, gangue, gypsum, grain slag, superfine slag powder, coal dust, bentonite, barite, marble, talc, refractory material

Get Price Talk Online

Introduction

Belt conveyor is a kind of machine that transfers the material continuously. The belt works under the effect of frictional force. It is not only the component to transfer the material, but also the components to transfer the force.

Vipeak belt conveyor is advanced and simple in structure, easy to maintain. Transfer capacity is more higher, and transfer distance more longer. It is widely used in mining, metallurgical and coal industry to transfer sandy or lump material, or packaged material.

In many situation, it is a very important component of nonstandard machinery.The belt conveyor is composed of standard parts, advanced and simple in structure, easy to maintain.

According to different transferring equipment, the transfer system can be one independently or multi-conveyors or combined with other transfer equipments. It can be installed horizontally or aslope to meet the needs of different transfer lines.
product introduction

Product Advantages

  • 01

    Grinding device

    • High quality of belt conveyor; large dip angle and high delivery value conveying slipping and maturing is could be avoided.

  • 02

    Classifier is available

    • Control horizontal positions; reduce the impact of material.

  • 03

    Star rack and V type grinding roller

    • Roller is the main part for power transmission.

  • 04

    Spacer protective measures

    • Belt conveyor get tension to avoid slipping; deflection is under control.

Product Specification


Belt width
Project
Belt width B(mm)
500
650
 800
1000
1200
Design Parameters
 Material: crushed stone，bulk density， Running stacking angle
Recommended size(mm)
 ≤150 ≤200 ≤300 ≤325 ≤375
Design throughput(t/h)
 150 150 250 350 500
Incline
 0~17°（The tilt angle limit is related to the material）
Theoretical belt speed
(22kw and above in brackets)m/s
 1.5 1.6 1.4 1.4 1.5(1.4)
Tightening method
 Spiral tensioning
Belt conveyor length (m)
 8≤L≤30
Diameter of driving drum (mm)
 Φ323 Φ375 Φ400 Φ424 Φ448
Diameter of reversing drum(mm)
 Φ271 Φ323 Φ375 Φ400 Φ424
Upper roller size
 Φ89×200 Φ89x250 Φ89x315 Φ108x380 Φ108x465
 Lower roller size
 Φ89×600 Φ89x750 Φ89x900 Φ108x1100 Φ108x1300
Model
 NN- 100 4×(4+1.5) NN- 100 4×(4+1.5) NN- 100 4×(4+1.5) NN- 100 5×(5+2) NN- 100 5×(5+2)
Any change of technical data shall not be advised additionally,The weight and dimensions shall be subject to the real object.
